| Product Code |
REF CM3050S |
| Manufacturer |
Leica Biosystems |
| Model |
CM3050 S |
| Condition |
Certified Pre-Owned |
| Warranty |
90 Day Parts Only |
| Unit of Measure |
each |
Cryocabinet
Height (arm rest level) 840 mm
Overall height 1040 mm
Weight
(incl. microtome, w/o specimen cooling) ca. 180 kg
Cryochamber
Temperature selection range 0° C to -40°C
Defrosting Automatic hot-gas defrost cycle, Automatic hot-gas defrost cycle,
programmable in 15-min increments; programmable in 15-min. increments;
1 automatic defrost cycle per 24 hours. 1 automatic defrost cycle per 24 hrs.
Duration: 6 - 12 minutes Duration: 6 - 12 minutes
Manual defrost cycle Manual defrost cycle
Refrigeration
Temperature selection range 0° C to -40°C
Defrosting Automatic hot-gas defrost cycle, programmable in 15-min increments; 1 automatic defrost cycle per 24 hours. Duration: 6 - 12 minutes. Manual defrost cycle.
Quick-freeze shelf
Maximum temperature - 43°C
Number of quick-freeze stations 10
Specimen cooling (Option)
Temperature range -10° C to -50°C
Defrosting Manual defrost cycle (electric)
Microtome
Rotary microtome
Section thickness setting 0.5 - 300 μm
Overall specimen feed 25 mm
Vertical stroke 59 mm
Specimen retraction 50 μm
Maximum specimen size 40 x 55 mm
Specimen orientation 8° (x-, y-, z-axis)
Trimming (6 thickness settings) 5 - 150 μm
Motorized coarse feed
- slow 500 μm/s
- fast 1,000 μm/s
Sectioning motor (Option):
Sectioning speed
- slow min. 0.1 mm/s
max. 100 mm/s
vmax 210 mm/s
- fast min. 0.1 mm/s
max. 170 mm/s
vmax 210 mm/s
Specifications
| Dimensions |
766 x 882 x 1040 mm (D x W x H)
|
| Weight |
180 kg |
